Auto High Speed OPP Labeling Machine for Round Bottle SPP-4000 manufacturer from China Shanghai PeiFeng Electronics Co.,Ltd

Payment Terms:	T/T
Place of Origin:	Shanghai, China (Mainland)

Product Detail

Model No.: SPP-4000

Production Capacity: 20sets/month

Delivery Date: 45days

Required Agent Type: manufacture

Means of Transport: Ocean,Land

Packing: Non-fumigating crate

Brand Name: SPP--Peifeng

Contract Period: 2 years

OPP labeling machine for round bottle
1 Material:OPP paper
2 Type:OPP Series
3 Capacity:50-300BPM

Feature:

Latest label-pasting main engine in Taiwan
Speed: 50-400-bottles/per minute
Junction line error: +/-1.5mm
Main engine is controlled by three-phase converter motor made of tainless steel SUS#304
PLC control system
Disc label-pasting and label-adsorbing
Include such mechanisms as label-providing, belt-conveying, label-cutting, wheels-attaching, vacuum-adsorbing, hot sol-conveyance
Hot sol providing machine is made in a hundred million Hertz. (Taiwan standard)
VAC and PUMP don't start working unless the hot sol machine gets to designed temperature.
STOP(ALARM) installation for label running-out
STOP installation for pasting failure
Applied to different specifications of packing for food, chemical, medicine, cosmetic and daily necessities
Bottle material: Plastics, glass, steel, etc
Made of stainless steel SUS#304 and imported T6 aluminum alloy after being anode hardened
Adjustable label-pasting speed of main engine
Imported optical-fiber electronic eye
Imported conveyer belt
Separation sets for each bottle line
Horizontally adjustable main engine
On-line production, simple and rapid installation
Alarm for missing label or gap
Vertically adjustable main engine (adjustment for label position)
Side wheels-attaching mechanical sets
Alarm for label running-out
Indicator light and alarm for abnormality

Specification:

Type	SPP-4000
Main engine size (lengthwidthheight)	4500L x 1600W x 2000H mm
Main engine production speed	limitation: 50-400-bottles/per minute
Main engine power supply	AC 3 phase220-380V
Main engine power	8kw
Label material	OPP Paper
Label length	10mm -300mm
Bottle/can diameter	50-106 mm
